TP-Link 5-Port Gigabit Easy Smart Switch with 4-Port PoE+

5 x 10/100/1000Mbps RJ45, 10 Gbps, 7.44 Mpps, 2K MAc, 16 KB Jumbo, 99.8 × 98 × 25 mm

Key Features

• Five 10/100/1000Mbps RJ45 ports
• Equipped with four 802.3af/at PoE+ ports with up to 30W for each port, data, and power can be transferred on one single cable
• Supports PoE power up to 120 W for all PoE ports
• Provides network monitoring, traffic prioritization, VLAN features, and PoE Auto Recovery
• Simple network set-up on top of plug-and-play connectivity
• Web-based user interface and Easy Smart Configuration Utility simplify configuration
• Fanless design lowers energy consumption and eliminates operating noise

Description

TP-Link TL-SG105MPE 5-Port Gigabit Easy Smart Switch with 4-Port PoE+
• Five 10/100/1000Mbps RJ45 ports
• Equipped with four 802.3af/at PoE+ ports with up to 30W for each port, data, and power can be transferred on one single cable
• Supports PoE power up to 120 W for all PoE ports*
• Provides network monitoring, traffic prioritisation, VLAN features, and PoE Auto Recovery
• Simple network set-up on top of plug-and-play connectivity
• Web-based user interface and Easy Smart Configuration Utility simplify configuration
• Fanless design lowers energy consumption and eliminates operating noise

Warranty Period: 5-Year

Specifications

Management features
Switch layer	L2
Web-based management	Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
Network
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Rate limiting	Yes
Port mirroring	Yes
Broadcast storm control	Yes
10G support	No
IGMP snooping	Yes
Data transmission
Jumbo frames	16
MAC address table	2000 entries
Switching capacity	10 Gbit/s
Jumbo frames support	Yes
Static route	Yes
Forwarding rate	7.44 Mpps
Security
Loop protection	Yes
IGMP snooping	Yes
Design
Rack mounting	No
Product colour	Black
Power
Power consumption (max)	137.01 W
Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
DC input voltage	53.5 V
Power source	DC/PoE
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Yes
Total Power over Ethernet (PoE) budget	120 W
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 95%
Weight & dimensions
Width	99.8 mm
Depth	98 mm
Height	25 mm
Packaging content
Cables included	LAN (RJ-45)
Packaging data
Cables included	LAN (RJ-45)
