DeepCool AG200 Processor Air cooler 9.2 cm Aluminium, Black 1 pc(s)

Intel LGA1700/1200/1151/1150/1155, AMD AM5/AM4, 1x 92 mm, 500 - 3050 RPM, 30.5 dB(A)

Description

EFFICIENT
COOLING POWER
Two direct contact copper heat pipes effectively transfer heat for optimal dissipation through the heat sink tower. The 92mm PWM fan outputs balanced airflow for performance and silence.

NEW FAMILY APPEARANCE
The AG200 adopts a new DeepCool family design and features a unique matrix fin array that densely packs each fin for a neat and firm construction.

EASY INSTALLATION
Compatible with multiple socket platforms from Intel and AMD with support for the latest changes. Ensure a proper mount pressure with the included brackets for a seamless installation.

Specifications

Performance
Suitable location	Processor
Fan connector	4-pin
Pulse-width modulation (PWM) support	Yes
Type	Air cooler
Rotational speed (min)	500 RPM
Rotational speed (max)	3050 RPM
Bearing type	Hydraulic
Fan diameter	9.2 cm
Supported processor sockets	LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5
Noise level (high speed)	30.5 dB
Maximum airflow	36.75 cfm
Maximum air pressure	2.89 mmH2O
Number of heat pipes	2
Number of fans	1 fan(s)
Heat pipes diameter	6 mm
Quantity per pack	1 pc(s)
Number of fan blades	5
Design
Fan connector	4-pin
Number of heat pipes	2
Number of fans	1 fan(s)
Product colour	Aluminium, Black
Number of fan blades	5
Ports & interfaces
Fan connector	4-pin
Power
Rated voltage	12 V
Rated current	0.13 A
Fan power consumption	1.56 W
Weight & dimensions
Width	119 mm
Depth	133 mm
Height	77 mm
Weight	304 g
Fan dimensions (W x D x H)	92 x 92 x 25 mm
Heat pipes diameter	6 mm
Radiator width	9.4 cm
Radiator depth	13.3 cm
Radiator height	5.7 cm
Technical details
Fan connector	4-pin
Packaging data
Package type	Box
Packaging content
Package type	Box
CPU socket spacer(s)	Yes
