Ubiquiti UISP -FIBER-XG network media converter 10000 Mbit/s Black, White

2.5Gbps uplink/10Gbps downlink, up to 20 km, 1x XG-PON port, 1x 2.5GbE RJ45 LAN port and 24V PoE in, 256 MB DDR, 32 MB NOR, 6W, UV-stabilized polycarbonate, black/white

Key Features

• (1) XG-PON port
• (1) 2.5GbE RJ45 LAN port and 24V PoE in

Description

An optical network unit that can deliver 2.5Gbps uplink/10Gbps downlink speeds over distances up to 20 km.

Specifications

Network
Maximum data transfer rate	10000 Mbit/s
Ethernet LAN data rates	100,1000,2500 Mbit/s
Ethernet interface type	2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Fiber optic connector	SC/APC
Performance
Maximum transfer distance	20000 m
Tx power (min)	2 dBmW
Tx power (max)	7 dBmW
Rx power (min)	-9 dBmW
Rx power (max)	-27 dBmW
Features
Reset button	Yes
Internal	No
LED indicators	Yes
Housing material	Polycarbonate (PC)
Product colour	Black, White
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Fiber ports quantity	1
Fiber optic connector	SC/APC
Power
Power consumption (max)	6 W
Input current	3 A
Power over Ethernet (PoE)	Yes
Sustainability
Sustainability compliance	Yes
Weight & dimensions
Width	100 mm
Depth	100 mm
Height	27 mm
Weight	220 g
Operational conditions
Operating temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	10 - 95%
Design
Internal	No
LED indicators	Yes
Housing material	Polycarbonate (PC)
Product colour	Black, White
Management features
Reset button	Yes
Certificates
Compliance certificates	CE, Federal Communications Commission (FCC), UKCA
Technical details
Sustainability compliance	Yes
Compliance certificates	CE, Federal Communications Commission (FCC), UKCA
