Ubiquiti UISP -P-Pro uninterruptible power supply (UPS) 480 W

SGCC steel, polycarbonate/ABS, Nano-SIM, LTE, 1x 10/100 MbE RJ45 LAN port, 3x Power TransPort ports [up to 250W (27V DC) output each, 100–240V AC, 1.3" touchscreen

Key Features

• (3) Power TransPort outputs
• Delivers up to 480W* (27V DC) to supported UISP devices
• (2) PSU bays with (1) 250W AC/DC Power Supply included
• (1) DC battery port for an external 24V lead-acid battery (not included)
• Supports SMS-over-LTE (Cat M1) notification**
• Compatible with UISP Console, UISP Router (installed with UISP Box), UISP Router Pro, UISP Switch (installed with UISP Box), UISP Switch Pro

Description

Uninterruptible power management system designed to support high-capacity WISP deployment sites.

Specifications

Power
Output power	480 W
Input operation voltage (min)	100 V
Input operation voltage (max)	240 V
Input frequency	50/60 Hz
Performance
LED indicators	Activity, Link, Status
Features
Output power	480 W
Input operation voltage (min)	100 V
Input operation voltage (max)	240 V
Input frequency	50/60 Hz
Power source type	AC
Compatibility	UISP Console, UISP Router (installed with UISP Box), UISP Router Pro, UISP Switch (installed with UISP Box), UISP Switch Pro
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Design
Compatibility	UISP Console, UISP Router (installed with UISP Box), UISP Router Pro, UISP Switch (installed with UISP Box), UISP Switch Pro
Product colour	White
LED indicators	Activity, Link, Status
Housing material	Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC), Steel
Control type	Touch
Operational conditions
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95%
Technical details
Sustainability compliance	Yes
Compliance certificates	CE, Federal Communications Commission (FCC)
Certificates
Compliance certificates	CE, Federal Communications Commission (FCC)
Sustainability
Sustainability compliance	Yes
Weight & dimensions
Width	442.4 mm
Depth	267.5 mm
Height	43.7 mm
Weight	4.16 kg
