Ubiquiti G5 Dome Ultra IP security camera Indoor & outdoor 2688 x 1512 pixels Ceiling/wall

1/2.4" CMOS, 4MP 2688 x 1512 (16:9) video, IR LED, Dual-core Arm Cortex-A7, PoE, IK06, Aluminum alloy, polycarbonate

Key Features

• 2K (4MP) video resolution
• Ultra-wide viewing angle (102.4°)
• 20 m (65 ft) IR night vision
• AI event detections
• Connect and power using PoE
• Optional Flush Mount for in-ceiling installation

Description

Ultra-compact and tamper-resistant 2K HD PoE camera with night vision designed for low-profile indoor security.

Specifications

Performance
Infrared (IR) cut-off filter	Yes
Processor model	ARM Cortex-A7
Type	IP security camera
Connectivity technology	Wired
Placement supported	Indoor & outdoor
Day/night mode	Yes
Built-in processor	Yes
Design
IK code	IK06
Form factor	Dome
Product colour	White
Mounting type	Ceiling/wall
Protection features	Vandal proof
Housing material	Aluminium, Polycarbonate (PC), Stainless steel
Camera
Lens viewing angle, horizontal	102.4°
Lens viewing angle, vertical	54.9°
Lens viewing angle, diagonal	120.6°
Image sensor
Sensor type	CMOS
Optical sensor size	25.4 / 2.4 mm (1 / 2.4")
Number of sensors	1
Lens system
Number of lenses	1
Night vision
Night vision	Yes
Night vision distance	20 m
LED type	IR
Video
Noise reduction	Yes
Image quality adjustment	Brightness, Colour depth, Contrast, DNR, Sharpness
Text caption overlay	Yes
Privacy masking	Yes
Noise reduction technology	2D noise reduction, 3D noise reduction
Maximum resolution	2688 x 1512 pixels
Video formats supported	H.264
Frame rate	30 fps
Total megapixels	4 MP
Network
Bluetooth	No
Ethernet interface type	Fast Ethernet
Ethernet LAN	Yes
Wi-Fi	No
Storage
Built-in HDD	No
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired
Management features
Reset button	Yes
Power
Power source type	PoE
AC input voltage	37 - 57 V
Power consumption (typical)	4.2 W
Operational conditions
Operating temperature (T-T)	-20 - 40 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Height	68.2 mm
Diameter	6.36 cm
Weight	175 g
Sustainability
Sustainability compliance	Yes
Compliance certificates	CE, Federal Communications Commission (FCC)
Packaging content
Number of cameras	1
Screws included	Yes
Mounting kit	Yes
Cables included	LAN (RJ-45)
Technical details
Sustainability compliance	Yes
Compliance certificates	CE, Federal Communications Commission (FCC)
