TP-Link Archer NX200 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) 5G White

5G AX1800 Wireless Dual-Band Gigabit Router

Key Features

• Boost Your 5G Speed - Take advantage of your advanced 5G network with download speeds up to 4.67 Gbps. Share your 5G network with multiple Wi-Fi devices and enjoy uninterrupted Ultra HD movies, blazingly fast file downloads, and smooth video chats and video conferences
• AX1800 Dual-Band Wi-Fi 6 Speed - 1201 Mbps (5 GHz) + 574 Mbps (2.4 GHz)
• Plug & Play - Enjoy 5G network right after inserting a SIM card
• EasyMesh-Compatible - Co-work with EasyMesh products, to provide a more flexible and cost-effective Mesh network with a single Wi-Fi name for seamless whole-home coverage
• Gigabit WAN/LAN Port - The gigabit WAN/LAN port enables NX200 to work as a traditional wireless router which is compatible with cable, fiber, and DSL modems

Description

Unrivaled Speed with 5G, Revolutionary Experience
Take advantage of your advanced 5G network with download speeds up to 4.67 Gbps. Share your 5G network with multiple Wi-Fi devices and enjoy uninterrupted Ultra HD movies, blazingly fast file downloads, and smooth video chats and video conferences. At the same time, NX200 is backward compatible with 4G mode.§

Plug and Play, Enjoy 5G Network Everywhere
Simple, just one SIM card
Traditional broadband or cable installation is expensive and time-consuming for your vacation home, farm, or suburban warehouse. Long contract periods also create headaches for short-rentals, pop-up venues, and temporary shops to access the internet. Archer NX200 ensures a comfortable and no-block network installation. Plug in your SIM card and enjoy high-speed internet!

Powerful Wi-Fi 6
Armed with WiFi 6 technology, NX200 is designed to deliver a huge boost in coverage, speed, and total capacity. Get on the latest mesh WiFi to enjoy the future network that loads faster and connects more.△

EasyMesh-Compatible Networking
Mesh networking creates smooth, fast, stable roaming. Eliminate Wi-Fi dead zones, expand your network, and fill your entire home with high-speed Wi-Fi.*

Available WAN Connection
The gigabit WAN/LAN port enables NX200 to work as a traditional wireless router which is compatible with cable, fiber, and DSL modems. And when it's set as a wireless router, its 5G/LTE connection works as a backup to provide a sustained and reliable internet connection for you.

Specifications

Ethernet LAN features
Ethernet WAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Mobile network
SIM card slot	Yes
3G/4G USB modem compatibility	No
Mobile network generation	5G
4G bands supported	700,800,850,900,1500,1800,2100,2300,2500,2600,3500,3700 MHz
3G standards	DC-HSDPA, HSPA, HSPA+, UMTS
4G standard	LTE-TDD & LTE-FDD
SIM card type	NanoSIM
5G bands supported	700,800,850,900,1800,2100,2300,2500,2600,3500,3700 MHz
3G bands supported	850,900,2100 MHz
Protocols
DMZ support	Yes
Supported network protocols	IPv4, IPv6
DHCP server	Yes
DHCP client	Yes
Security
VPN support	PPTP VPN, IPSec VPN , OpenVPN
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Firewall security	IPv4 SPI Firewall, IPv6 Firewal
Firewall	Yes
DoS attack prevention	Yes
DMZ support	Yes
Parental control	Yes
Access Control List (ACL)	Yes
Performance
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
Mac operating systems supported	Yes
Linux operating systems supported	Yes
WAN connection
Ethernet WAN	Yes
SIM card slot	Yes
3G/4G USB modem compatibility	No
WAN connection type	RJ-45
Wireless LAN features
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	1201 Mbit/s
Modulation	1024-QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (first band)	574 Mbit/s
WLAN data transfer rate (second band)	1201 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Network
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN	Yes
VPN support	PPTP VPN, IPSec VPN , OpenVPN
Ethernet LAN data rates	10,100,1000 Mbit/s
Port triggering	Yes
Number of guest networks (5 GHz)	1
Number of guest networks (2.4 GHz)	1
Dynamic DNS (DDNS)	Yes
Ports & interfaces
USB port	No
Ethernet LAN (RJ-45) ports	3
Management features
WPS push button	Yes
Reset button	Yes
Quality of Service (QoS) support	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
MU-MIMO technology	Yes
Design
Product type	Tabletop router
On/off switch	Yes
Product colour	White
Certificates
Compliance certificates	CE, RoHS
Software
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
Mac operating systems supported	Yes
Linux operating systems supported	Yes
Packaging content
Cables included	LAN (RJ-45)
AC adapter included	Yes
Quick installation guide	Yes
Antenna
Antenna design	Internal
Detachable antenna(s)	Yes
Antennas quantity	10
Power
Power source type	AC
Output voltage	12 V
Output current	2 A
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Operational conditions
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90%
System requirements
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
Mac operating systems supported	Yes
Linux operating systems supported	Yes
Browser supported	Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
Weight & dimensions
Width	99 mm
Height	190 mm
Depth	99 mm
Packaging data
Cables included	LAN (RJ-45)
AC adapter included	Yes
Quick installation guide	Yes
Technical details
Compliance certificates	CE, RoHS
