Ubiquiti UDB-Pro Network bridge 866.7 Mbit/s White

Device Bridge Pro, pole mount, 2x GbE LAN, PoE/PoE+, WiFi 5 GHz, 867 Mbps, UV-resistant polycarbonate, IPX6, white

Key Features

• Link at 5+ km distances with a point-to-point connection to another Device Bridge Pro, or uplink seamlessly with UniFi WiFi Auto-Link
• (2) GbE ports with (1) PoE output for PoE devices
• Powered using PoE/PoE+*
• Pole mounting
• Weatherproof (outdoor exposed)
• Sold as a single unit

Description

5 GHz wireless bridge with PoE output that connects at 5+ km distances or seamlessly uplinks to UniFi WiFi.

Specifications

Data transmission
Maximum data transfer rate	866.7 Mbit/s
Antenna
Antenna gain level (max)	19 dBi
Antenna design	Internal
Antenna type	2x2
Wireless LAN features
Signal strength	25 dBm
Outdoor range	5+ km
Frequency band	5 GHz
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, QPSK
Antenna gain level (max)	19 dBi
Wi-Fi	Yes
Wi-Fi band	Single-band (5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Antenna type	2x2
Network
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Outdoor range	5+ km
Frequency band	5 GHz
Ports & interfaces
Ethernet LAN	Yes
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	2
Power over Ethernet plus (PoE+) ports quantity	1
Security
Security algorithms	WPA2-AES
Features
Product type	Network bridge
Reset button	Yes
International Protection (IP) code	IPX6
Power LED	Yes
Material	Polycarbonate (PC), Stainless steel
LED indicators	LAN, Power, Signal strength
Product colour	White
Mounting type	Pole
Power
Power consumption (max)	9 W
Power source type	DC, PoE
DC input voltage	42.5 - 57 V
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) voltage	48 V
Operational conditions
Operating temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	5 - 95%
Management features
LED indicators	LAN, Power, Signal strength
Certificates
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC)
Technical details
Material	Polycarbonate (PC), Stainless steel
Product colour	White
Quantity per pack	1 pc(s)
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC)
Weight & dimensions
Weight	515 g
Width	189.5 mm
Depth	64.3 mm
Height	189.5 mm
Indication
Power LED	Yes
Packaging content
Cables included	AC
Mounting bracket(s) included	Yes
Power supply included	Yes
Packaging data
Quantity per pack	1 pc(s)
