1 8

Ubiquiti

Ubiquiti UniFi Flex 2.5G Managed L2 2.5G Ethernet (100/1000/2500) Desktop/Wall-Mounting White

$376.00 AUD
$376.00 AUD
Sale Sold out

Use the contact form below to check availability.

60 Gbps, Forwarding Rate 45 Mpps, Supported VLANs 256, AC/DC, external, 15W

Description



Specifications

Management features
Switch layer L2
Switch type Managed
Multicast support Yes
Ports & interfaces
SFP+ module slots quantity 1
Basic switching RJ-45 Ethernet ports quantity 8
Basic switching RJ-45 Ethernet ports type 2.5G Ethernet (100/1000/2500)
2.5G Ethernet (copper) ports quantity 8
10G Ethernet (copper) ports quantity 1
Network
Number of VLANs 256
VLAN support Yes
Rate limiting Yes
Port mirroring Yes
Flow control support Yes
Ethernet LAN data rates 10,100,1000,2500 Mbit/s
Broadcast storm control Yes
10G support Yes
Data transmission
MAC address table 4000 entries
Switching capacity 60 Gbit/s
Jumbo frames support Yes
Forwarding rate 45 Mpps
Throughput 30 Gbit/s
Number of VLANs 256
Security
Loop protection Yes
Multicast features
Multicast support Yes
Design
DIN rail mounting Yes
Wall mountable Yes
Product colour White
Form factor Desktop/Wall-Mounting
LED indicators Activity, Link, Power, Status
Housing material Polycarbonate (PC)
Power
Power consumption (max) 17 W
Power supply included No
Input current 3.9 A
Power source PoE/USB
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating temperature (T-T) -20 - 45 °C
Operating relative humidity (H-H) 10 - 90%
Virtual LAN features
Number of VLANs 256
VLAN support Yes
Weight & dimensions
Width 212.9 mm
Depth 99.4 mm
Height 33.5 mm
Weight 567 g
Technical details
Compliance certificates CE, Federal Communications Commission (FCC), Industry Canada (IC)
Certificates
Compliance certificates CE, Federal Communications Commission (FCC), Industry Canada (IC)
Other features
Ethernet LAN data rates 10,100,1000,2500 Mbit/s
