Ubiquiti UniFi Flex 2.5G PoE Managed L2 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) Desktop/Wall-Mounting White

8x 2.5 GbE PoE++, 1x 10G SFP+ or 10/5/2.5/1 GbE RJ45 combination port, 60W PoE++, 60 Gbps, white

Key Features

• (8) 2.5 GbE PoE++ output ports
• (1) 10 GbE PoE+++ input port for power / SFP+ port combo (57W PoE availability with PoE+++ input / 37W PoE availability with PoE++ input / 12W PoE availability with PoE+ input)
• 196W PoE availability with optional AC power adapter

Description

Flexible, 8-port 2.5 GbE PoE++ switch with a 10 GbE RJ45/SFP+ combination uplink port that can be powered with PoE+++ or an AC power adapter*.

*AC power adapter sold separately.

Specifications

Management features
Reset button	Yes
Switch layer	L2
Switch type	Managed
Multicast support	Yes
Ports & interfaces
SFP+ module slots quantity	1
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	2.5G Ethernet (100/1000/2500)
Power connector	DC-in jack
2.5G Ethernet (copper) ports quantity	8
10G Ethernet (copper) ports quantity	1
Network
Rate limiting	Yes
Port mirroring	Yes
Flow control support	Yes
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Broadcast storm control	Yes
10G support	Yes
Data transmission
Switching capacity	60 Gbit/s
Jumbo frames support	Yes
Forwarding rate	44.64 Mpps
Throughput	30 Gbit/s
Security
Loop protection	Yes
Multicast features
Multicast support	Yes
Design
Reset button	Yes
DIN rail mounting	Yes
Wall mountable	Yes
Product colour	White
Form factor	Desktop/Wall-Mounting
LED indicators	Activity, Link, PoE, Power, Status
Housing material	Polycarbonate (PC)
Power
Power consumption (max)	17 W
Power supply included	No
Input current	3.9 A
DC input voltage	54 V
Power source	AC/DC/PoE
Power connector	DC-in jack
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port	15.4 W
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	8
Total Power over Ethernet (PoE) budget	196 W
Power over Ethernet (PoE) voltage	57 V
Power over Ethernet 4PPoE (PoE++) ports quantity	1
Operational conditions
Operating temperature (T-T)	-20 - 45 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	212.9 mm
Depth	99.4 mm
Height	33.5 mm
Weight	567 g
Technical details
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC)
Certificates
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC)
Other features
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
