TP-Link Omada ES228GMP network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

ES228GMP Omada 28-Port Gigabit Easy Managed Switch with 24-Port PoE+

Key Features

• 26× 10/100/1000Mbps RJ45 ports (24× 802.3af/at-compliant PoE+)
• 2× Gigabit SFP port
• 384W Power Budget, with up to 30W for each PoE port
• Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
• Centralized Cloud Management via the web or the Omada app
• Up to 250m PoE, QoS△, PoE Auto Recovery, and Port Isolation for reliable surveillance networking
• Automatic Loop Prevention, VLAN, and IGMP Snooping
• Durable metal casing and rack-mountable design

Description

Omada Cloud Essentials — A Free and Easy Cloud-Based Network Management
Omada Cloud Essentials is a free, easy-to-use version of the Omada Cloud-based Controller. It provides cloud-based centralized management and monitoring for the Omada networking system, covering access points, switches, and gateways, ideal for surveillance networks and small businesses.

Specifications

Management features
Switch layer	L2
Switch type	Managed
Web-based management	Yes
Quality of Service (QoS) support	Yes
Multicast support	Yes
Unified static configuration	Yes
Cloud-managed	Yes
Ports & interfaces
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	26
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	26
Copper ethernet cabling technology	10BASE-T, 100BASE-X, 1000BASE-T, 1000BASE-X
Network
Networking standards	IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Number of VLANs	32
Copper ethernet cabling technology	10BASE-T, 100BASE-X, 1000BASE-T, 1000BASE-X
VLAN support	Yes
Port mirroring	Yes
Link aggregation	Yes
Flow control support	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Broadcast storm control	Yes
Auto MDI/MDI-X	Yes
10G support	No
Fast leave	Yes
Virtual LAN features	MTU VLAN, Port-based VLAN, Tagged VLAN
IGMP snooping	Yes
Data transmission
Jumbo frames	15000
MAC address table	8000 entries
Switching capacity	56 Gbit/s
Store-and-forward	Yes
Jumbo frames support	Yes
Packet buffer memory	4 MB
Forwarding rate	41.66 Mpps
Number of VLANs	32
Security
IGMP snooping	Yes
Queue scheduling algorithms	Weighted Round Robin (WRR)
DHCP features	DHCP client
Multicast features
Multicast support	Yes
Design
Rack mounting	Yes
Product colour	Black
LED indicators	Yes
Housing material	Metal
Number of fans	2 fan(s)
Certification	FCC, CE, RoHS
Performance
Noise level	46.2 dB
Flash memory	64 MB
Firmware upgradeable	Yes
Mean time between failures (MTBF)	224143 h
Fanless	No
Packet buffer memory	4 MB
Power
Power consumption (max)	454.8 W
Power supply included	Yes
Surge protection voltage	6 kV
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Surge protection	Yes
Power source	AC
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port	30 W
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	24
Total Power over Ethernet (PoE) budget	384 W
Power over Ethernet (PoE) type supported	PoE+
Operational conditions
Operating temperature (T-T)	-5 - 45 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Heat dissipation	1546.15 BTU/h
Virtual LAN features
Number of VLANs	32
VLAN support	Yes
Virtual LAN features	MTU VLAN, Port-based VLAN, Tagged VLAN
Weight & dimensions
Width	440 mm
Depth	330 mm
Height	44 mm
Packaging content
Rack mount kit	Yes
Quick start guide	Yes
Manual	Yes
Cables included	AC
Technical details
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS
Certificates
Certification	FCC, CE, RoHS
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS
Packaging data
Rack mount kit	Yes
Quick start guide	Yes
Manual	Yes
Cables included	AC
Other features
Ethernet LAN data rates	10,100,1000 Mbit/s
