Ubiquiti Dream 7 wireless router 2.5 Gigabit Ethernet Tri-band (2.4 GHz / 5 GHz / 6 GHz) White

UDR7 (15W), 10G SFP+, 2.5 GbE RJ45, 3x 2.5 GbE RJ45 including (1) PoE, 160 m² (1,750 ft²), WiFi 7, PoE, microSD

Description

Desktop 10G Cloud Gateway with integrated WiFi 7, PoE switch, microSD storage, and full UniFi application support.

Specifications

Ethernet LAN features
Ethernet WAN	Yes
Ethernet LAN interface type	2.5 Gigabit Ethernet
Ethernet LAN	Yes
Ethernet LAN data rates	2500 Mbit/s
DSL features
DSL WAN	No
Mobile network
SIM card slot	No
3G/4G USB modem compatibility	No
Network
Routing protocols	OSPF
MAC address table	2000 entries
Ethernet LAN interface type	2.5 Gigabit Ethernet
Ethernet LAN	Yes
Networking standards	IEEE 802.1Q
Ethernet LAN data rates	2500 Mbit/s
VPN server	Identity Endpoint One-Click VPN, Teleport Zero-Configuration VPN, WireGuard, OpenVPN, L2TP
Policy-based routing	Yes
Multicast support	Yes
Load balancing system	Yes
Maximum coverage	160 m²
Maximum Tx power (5 GHz)	26 dBmW
Maximum Tx power (2.4 GHz)	23 dBmW
Performance
Processor frequency	1500 MHz
Processor cores	4
Compatible memory cards	MicroSD (TransFlash)
Built-in processor	Yes
Internal memory	3000 MB
Memory card slot(s)	Yes
Processor architecture	ARM Cortex-A53
Packaging content
Number of products included	1 pc(s)
Manual	Yes
Cables included	AC
WAN connection
Ethernet WAN	Yes
DSL WAN	No
SIM card slot	No
3G/4G USB modem compatibility	No
Wireless LAN features
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
WLAN data transfer rate (max)	5700 Mbit/s
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 6 GHz)
WLAN data transfer rate (first band)	688 Mbit/s
WLAN data transfer rate (second band)	4300 Mbit/s
WLAN data transfer rate (third band)	5700 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Ports & interfaces
USB port	No
Ethernet LAN (RJ-45) ports	4
Compatible memory cards	MicroSD (TransFlash)
Memory card slot(s)	Yes
Fiber optic connector	SFP+
Management features
Web-based management	Yes
Reset button	Yes
Quality of Service (QoS) support	Yes
MU-MIMO technology	Yes
MIMO	Yes
Security
Security algorithms	PPSK, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3
MAC address table	2000 entries
Firewall	Yes
Filtering	Yes
Protocols
Routing protocols	OSPF
DHCP server	Yes
Design
Product type	Tabletop router
LED indicators	Status
Housing material	Polycarbonate (PC)
Product colour	White
Display type	LCM
Built-in display	Yes
Certificates
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC)
Other features
Internal memory	3000 MB
Antenna
Antenna design	Internal
Antenna gain level (max)	7 dBi
Features
Processor frequency	1500 MHz
Processor cores	4
Built-in processor	Yes
Internal memory	3000 MB
Processor architecture	ARM Cortex-A53
Bluetooth	Yes
Number of simultaneously connected devices (max)	300
Power
Power supply	50 W
Power source type	AC, PoE
Power over Ethernet (PoE)	Yes
Power consumption (typical)	26 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power over Ethernet (PoE) voltage	57 V
Operational conditions
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Weight & dimensions
Width	110 mm
Weight	1.1 kg
Height	184.1 mm
Depth	110 mm
Packaging data
Manual	Yes
Cables included	AC
Number of products included	1 pc(s)
Technical details
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC)
