TP-Link Omada POE5430G-M2 PoE adapter 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet 54 V

Omada 2.5G Passive PoE Adapter, 54V, 0.56A, 30W, 2 x RJ-45, White, 110 x 57 x 36mm

Key Features

• 54V passive PoE supported
• Convenient wall-mount design
• Auto-determine the necessary power requirements
• 2.5Gbps/1000Mbps/100Mbps/10Mbps speed support
• Plug-and-Play, requires no configuration
• Maximum power up to 30W

Description

The passive PoE adapter POE5430G-M2 can be used to simultaneously supply power and transmit data to a passive PoE device.

Specifications

Network
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Ethernet interface type	2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Power over Ethernet (PoE) type supported	Passive PoE
Power over Ethernet (PoE) voltage	54 V
Features
Wall mountable	Yes
Easy to install	Yes
Plug and Play	Yes
Product colour	White
LED indicators	Power
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
Power
Output power	30 W
Power over Ethernet (PoE) voltage	54 V
Input current	0.56 A
Certificates
Compliance certificates	BSMI, CE, Federal Communications Commission (FCC), KC, UL
Operational conditions
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	-5 - 40 °C
Operating temperature (T-T)	-40 - 70 °F
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	57 mm
Depth	110 mm
Height	36 mm
Packaging content
Power cord included	Yes
Quick installation guide	Yes
Technical details
Operating temperature (T-T)	-40 - 70 °F
Input current	0.56 A
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Ethernet interface type	2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Compliance certificates	BSMI, CE, Federal Communications Commission (FCC), KC, UL
Indication
LED indicators	Power
