TP-Link SG2206MP network switch L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE)

RJ-45, SFP, PoE+, 63W, 30W, 12Gbps

Key Features

• 5× Gigabit RJ45 ports (4× PoE+) and 1× Gigabit SFP slot
• 63W total PoE budget with up to 30W for each PoE+ port*
• Centralized cloud management via the web or the Omada app†
• Standalone management via web, CLI, SNMP, and RMON
• Static Routing helps route internal traffic for higher efficiency
• VLAN, ACL, QoS, and IGMP Snooping
• Durable metal casing and desktop/wall mounting design

Description

Multiple Application Scenarios

Wi-Fi Coverage
Works with Access Points

Surveillance
Works with IP Cameras

Conference Call
Works with IP Phones

Wired Connections
Works with Non-PoE Devices such as PCs and Printers

Specifications

Management features
Switch layer	L2
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	1
Gigabit Ethernet (copper) ports quantity	5
Network
Active link detection	Yes
VLAN support	Yes
Spanning tree protocol	Yes
Routing entries	230
Rate limiting	Yes
Port mirroring	Yes
Link aggregation	Yes
IGMP snooping	Yes
Data transmission
Jumbo frames	9
MAC address table	8000 entries
Switching capacity	12 Gbit/s
Jumbo frames support	Yes
Packet buffer memory	4.1 MB
Security
Loop protection	Yes
IGMP snooping	Yes
DHCP features	DHCP relay, DHCP server
Design
Rack mounting	Yes
Stackable	Yes
Power
Power consumption (max)	73.7 W
Power supply included	Yes
Number of power supply units	1
Input current	1.31 A
DC input voltage	53.5 V
Power source	DC
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port	30 W
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	4
Total Power over Ethernet (PoE) budget	63 W
Virtual LAN features
VLAN support	Yes
Weight & dimensions
Width	158 mm
Depth	100.7 mm
Height	25.4 mm
Performance
Stackable	Yes
Packet buffer memory	4.1 MB
