TP-Link TL-WN725N network card WLAN 150 Mbit/s

USB 2.0, LED, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, 2.400-2.4835GHz

Key Features

• Sleek miniature design so small that once plugged in, can be left in a Laptop’s USB port
• Speedy wireless transmission at up to 150Mbps ideal for video streaming or internet calls
• Advanced Security: Supports 64/128 WEP, WPA, PA2/WPA-PSK/WPA2-PSK(TKIP/AES)
• Connect in no time with easy setup utility in 14 languages
• Windows 10/8.1/8/7/XP, Mac OS X, Linux

Description

Great Surfing Experience with Nano USB Adapter
As a Wireless N Nano USB adapter, TL-WN725N allows users to connect a desktop or notebook computer to a wireless network at speed of up to 150Mbps, which is ideal for smooth video streaming, voice streaming and online gaming.

Miniature Design Brings Infinite Convenience
TL-WN725N is designed to be as convenient as possible. With its miniature size and sleek design, users can connect the nano adapter to any USB port and leave it there, no matter when they are traveling or at home.

Easy Setup
A friendly user interface on a CD for simple installation

Advanced Security
WPA/WPA2 encryption standards ensure wireless connection's safety.

Operating System
Supports Windows, Mac OS, Linux

Specifications

Ports & interfaces
Internal	No
USB version	2.0
Connectivity technology	Wireless
Host interface	USB
Interface	WLAN
Bandwidth
Maximum data transfer rate	150 Mbit/s
Wireless LAN features
Wi-Fi band	Single-band (2.4 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wi-Fi	Yes
WLAN data transfer rates supported	11,54,150 Mbit/s
Antenna
Antenna	Yes
Frequency range	2.4 - 2.4835 GHz
Network
Wi-Fi band	Single-band (2.4 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Maximum data transfer rate	150 Mbit/s
Wi-Fi	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Modulation	16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM
WLAN data transfer rates supported	11,54,150 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA-PSK, WPA-TKIP, WPA2, WPA2-PSK
Frequency range	2.4 - 2.4835 GHz
Design
Internal	No
Product colour	Black
Antenna	Yes
LED indicators	Status
Transmitting power (CE)	20 dBm
Transmitting power (FCC)	20 dBm
Operating modes	Infrastructure mode
Component for	PC/Laptop
Antenna design	Internal
Power
USB powered	Yes
System requirements
Windows operating systems supported	Windows 7 Professional x64, Windows 8.1 Pro, Windows 10, Windows 7 Starter, Windows 8.1 Pro x64, Windows 10 Education, Windows 7 Starter x64, Windows 8.1 x64, Windows 10 Education x64, Windows 7 Ultimate, Windows 10 Enterprise, Windows 7 Ultimate x64, Windows 10 Enterprise x64, Windows 7 x64, Windows 10 Home, Windows 8, Windows 10 Home x64, Windows 7, Windows 8 Enterprise, Windows 10 IOT Core, Windows 7 Enterprise, Windows 8 Enterprise x64, Windows XP, Windows 10 IoT Enterprise, Windows 7 Enterprise x64, Windows 8 Pro, Windows XP Home, Windows 10 Pro, Windows 7 Home Basic, Windows 8 Pro x64, Windows XP Home x64, Windows 10 Pro x64, Windows 7 Home Basic x64, Windows 8 x64, Windows XP Professional, Windows 10 x64, Windows 7 Home Premium, Windows 8.1, Windows XP Professional x64, Windows 7 Home Premium x64, Windows 8.1 Enterprise, Windows 7 Professional, Windows 8.1 Enterprise x64
Mac operating systems supported	Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina
Linux operating systems supported	Yes
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Sustainability
Sustainability compliance	Yes
Weight & dimensions
Width	18.6 mm
Depth	15 mm
Height	7.1 mm
Weight	2.1 g
Package width	138 mm
Package depth	128 mm
Package height	30 mm
Package weight	90 g
Packaging data
Package width	138 mm
Package depth	128 mm
Package height	30 mm
Package weight	90 g
Quick installation guide	Yes
Packaging content
Quick installation guide	Yes
Resource CD	Yes
Performance
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA-PSK, WPA-TKIP, WPA2, WPA2-PSK
Windows operating systems supported	Windows 7 Professional x64, Windows 8.1 Pro, Windows 10, Windows 7 Starter, Windows 8.1 Pro x64, Windows 10 Education, Windows 7 Starter x64, Windows 8.1 x64, Windows 10 Education x64, Windows 7 Ultimate, Windows 10 Enterprise, Windows 7 Ultimate x64, Windows 10 Enterprise x64, Windows 7 x64, Windows 10 Home, Windows 8, Windows 10 Home x64, Windows 7, Windows 8 Enterprise, Windows 10 IOT Core, Windows 7 Enterprise, Windows 8 Enterprise x64, Windows XP, Windows 10 IoT Enterprise, Windows 7 Enterprise x64, Windows 8 Pro, Windows XP Home, Windows 10 Pro, Windows 7 Home Basic, Windows 8 Pro x64, Windows XP Home x64, Windows 10 Pro x64, Windows 7 Home Basic x64, Windows 8 x64, Windows XP Professional, Windows 10 x64, Windows 7 Home Premium, Windows 8.1, Windows XP Professional x64, Windows 7 Home Premium x64, Windows 8.1 Enterprise, Windows 7 Professional, Windows 8.1 Enterprise x64
Mac operating systems supported	Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina
Linux operating systems supported	Yes
Technical details
Harmonized System (HS) code	85176990
Sustainability compliance	Yes
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS
Logistics data
Harmonized System (HS) code	85176990
Other features
Harmonized System (HS) code	85176990
