Ubiquiti AMO-5G13 network antenna Sector antenna 13 dBi

Next-Gen 2x2 Dual Polarity MIMO Omni Antenna, 5 GHz, 13 dBi

Description

Omnidirectional Coverage

airMAX Omni is a Carrier Class 2x2 Dual Polarity MIMO Omnidirectional Antenna that was designed to seamlessly integrate with RocketM radios (RocketM sold separately).

Pair the RocketM’s radio with the airMAX Omni’s reach to create a powerful, 360° omnidirectional basestation.. This seamless integration gives network architects unparalleled flexibility and convenience.

Utilize airMAX Technology
Unlike standard Wi-Fi protocol, Ubiquiti’s Time Division Multiple Access (TDMA) airMAX protocol allows each client to send and receive data using pre-designated time slots scheduled by an intelligent AP controller.

This “time slot” method eliminates hidden node collisions and maximizes airtime efficiency. It provides many magnitudes of performance improvements in latency, throughput, and scalability compared to all other outdoor systems in its class.

Intelligent QoS
Priority is given to voice/video for seamless streaming.

Scalability
High capacity and scalability.

Long Distance
Capable of high-speed, carrier-class links.

Latency
Multiple features dramatically reduce noise.

Specifications

Performance
Antenna gain level (max)	13 dBi
Frequency band	5 GHz
Vertical beam width (5 GHz)	2°
Horizontal beam width (5 GHz)	7°
Features
Antenna gain level (max)	13 dBi
Frequency band	5 GHz
Antenna type	Sector antenna
Voltage Standing Wave Ratio (VSWR)	1.5:1
Vertical beam width (5 GHz)	2°
Purpose	Outdoor
Polarization	Dual polarization
Mounting	Wall
Horizontal beam width (5 GHz)	7°
Product colour	White
Certification	EN 302 326 DN2
Technical details
Harmonized System (HS) code	85177100
Weight & dimensions
Weight	820 g
Width	799 mm
Depth	90 mm
Height	65 mm
Packaging content
Quantity per pack	1 pc(s)
Logistics data
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85177100
