TP-Link EAP110 wireless access point 300 Mbit/s White Power over Ethernet (PoE)

Fast Ethernet (RJ-45), 2.8 W, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, 2.4-2.4835GHz

Key Features

• Cloud centralized management and Omada app for ultra convenience and easy management
• Supports passive PoE for convenient installation up to 100meters2
• Ceiling mounting design with chassis makes it easy to deploy on a wall or ceiling
• The captive portal provides modern and professional user sign-in experience
• Facebook check-in and SMS authentication expands your social exposure with secured technology
• Multi-SSID divides multiple wireless networks for different user groups
• Enterprise class Wi-Fi security help to decrease network security threats
• Supports management VLAN for an enhanced network management

Description

Flexible Placement
Easy mounting design & PoE
The EAP’s elegant appearance and easy mounting design with chassis make it easy to be integrated seamlessly into any wall or ceiling surface to blend in with most interior decorations. EAP110 supports Passive PoE to make deployment effortless and flexible.

Cloud Centralized Management
- Anytime, Anywhere
Omada Hardware Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.

Efficient Guest Authentication with Facebook and SMS Support
Captive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.

Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.

Meet Our New Hero Product!
The OC200 Omada Hardware Controller is dedicated to providing centralized management for the whole Omada network.

Specifications

Performance
2.4 GHz	Yes
5 GHz	No
Wireless isolation	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Automatic channel selection	Yes
Syslog	Yes
Maximum data transfer rate	300 Mbit/s
Ethernet LAN data rates	10,100 Mbit/s
Frequency band	2.4 - 2.4835 GHz
Web-based management	Yes
VLAN support	Yes
Reset button	Yes
Receiver sensitivity	300M: -71dBm@10% PER 150M: -75dBm@10% PER 54M: -78dBm@10% PER 11M: -93dBm@8% PER 6M: -92dBm@10% PER 1M: -96dBm@8% PER
Rate limiting	Yes
Quality of Service (QoS) support	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x
Certification	FCC, RoHS
Remote Authentication Dial-In User Service (RADIUS)	Yes
Features
2.4 GHz	Yes
5 GHz	No
Wireless isolation	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Automatic channel selection	Yes
Maximum data transfer rate	300 Mbit/s
Ethernet LAN data rates	10,100 Mbit/s
Frequency band	2.4 - 2.4835 GHz
VLAN support	Yes
Receiver sensitivity	300M: -71dBm@10% PER 150M: -75dBm@10% PER 54M: -78dBm@10% PER 11M: -93dBm@8% PER 6M: -92dBm@10% PER 1M: -96dBm@8% PER
Rate limiting	Yes
Quality of Service (QoS) support	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x
Cabling technology	10/100Base-T(X)
Transmitting power (CE)	21 dBm
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Virtual LAN features	SSID-based VLAN assignment
Security
Number of SSID supported	8
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, HTTPS, SNMP, SNMPv2, SSH, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK
MAC address filtering	Yes
Access Control List (ACL)	Yes
Remote Authentication Dial-In User Service (RADIUS)	Yes
Service Set Identifier (SSID) features	Multiple SSIDs
Management features
Syslog	Yes
Web-based management	Yes
Ports & interfaces
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Cabling technology	10/100Base-T(X)
Power
Power consumption (typical)	2.8 W
Power over Ethernet (PoE)	Yes
AC input voltage	24 V
Design
Placement	Ceiling, Wall
Reset button	Yes
LED indicators	Power
Product colour	White
Certification	FCC, RoHS
Antenna
Antenna type	Internal
Antennas quantity	2
Antenna gain level (max)	4 dBi
Antenna direction type	Omni-directional
Technical details
Harmonized System (HS) code	85176990
Certificates
Certification	FCC, RoHS
Software
Access Control List (ACL)	Yes
Weight & dimensions
Width	189.4 mm
Depth	172.3 mm
Height	29.5 mm
Packaging data
Quick start guide	Yes
Mounting kit	Yes
PoE adapter included	Yes
Package type	Box
Cables included	AC
Packaging content
Quick start guide	Yes
Mounting kit	Yes
PoE adapter included	Yes
Cables included	AC
Quantity per pack	1 pc(s)
Package type	Box
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
Logistics data
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
