ATEN 2-Port USB 4K DisplayPort 1.2 KVM Switch (KVM cables included)

2-Port USB 4K DisplayPort 1.2 KVM Switch (KVM cables included)

Key Features

• Superior video quality – 4K UHD (3840 × 2160 @ 60 Hz) and 4K DCI (4096 x 2160 @ 60 Hz)
• Computer selection via remote port selector, hotkeys, and USB mouse; bus-powered design
• Supports MST (Multi-Stream Transport)2, enabling multiple monitors to be used via a single DisplayPort connector
• Multiplatform support – Windows, Mac, Sun, and Linux

Description

With the ever-growing demand for higher video quality and the evolution of DisplayPort technology, 4K-enabled computers and displays are now widely adopted in visually-intensive and commercial applications. Offering up to 4K resolution, the ATEN CS782DP is at home amongst these demanding scenarios and technological advancements.
1x CS782DP 2-Port USB DisplayPort KVM Switch
2x LIN5-20K1-K12G DisplayPort Cables
2x LIN6-04U1-V1BG USB Cables
2x LIN5-0205-21CG Audio Cables
1x Remote Port Selector
1x User Instructions

Specifications

Video
HD type	4K Ultra HD
Video bandwidth	60 Hz
Maximum resolution	4096 x 2160 pixels
Ports & interfaces
Console ports	3.5mm headphone, DisplayPort, USB A
USB connector type	USB Type-A, USB Type-B
Number of microphone inputs	1
DisplayPorts quantity	2
Number of computers controlled	2
Keyboard port type	USB
Mouse port type	USB
Video port type	DisplayPort
Audio connections	Yes
Headphone outputs	1
USB 2.0 Type-B ports quantity	2
Performance
HD type	4K Ultra HD
Video bandwidth	60 Hz
Maximum resolution	4096 x 2160 pixels
Scan interval	3,5,10,20 s
Design
Product colour	Black
Rack mounting	No
LED indicators	Yes
Hot keys	Yes
Housing material	Plastic
Display
Built-in display	No
Power
Power source	DC
Power consumption (typical)	2.18 W
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80%
Storage relative humidity (H-H)	0 - 80%
Weight & dimensions
Width	93 mm
Depth	93.7 mm
Height	26.8 mm
Weight	543 g
Package width	59 mm
Package depth	239 mm
Package height	175 mm
Package weight	687 g
Packaging data
Package width	59 mm
Package depth	239 mm
Package height	175 mm
Package weight	687 g
Packaging content
Quick installation guide	Yes
Manual	Yes
Logistics data
Master (outer) case width	328 mm
Master (outer) case length	497 mm
Master (outer) case height	196 mm
Master (outer) case gross weight	7.71 kg
Products per master (outer) case	10 pc(s)
Master (outer) case net weight	5.43 kg
Harmonized System (HS) code	85176200
Other features
Hot keys	Yes
