CyberPower OLS1000ERT2UA uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 900 W 8 AC outlet(s)

Online, 1000 VA, 900 W, Sine Wave, IEC C13 x 8, 12 V, 9 Ah, 2U

Key Features

• Online (Double Conversion) UPS Topology
• Generator Compatible
• Zero Transfer Time
• Extended Battery Module Auto-detection
• Critical/Non-critical Load Outlets
• Phone/Fax/Modem/DSL/Network Protection
• Variable Speed Fans
• PowerPanel® Management Software
• Rack/Tower Convertible Configurations

Description

CyberPower OLS1000ERT2UA is a high-performance UPS featuring online double-conversion topology, which provides seamless Pure Sine Wave power for mission-critical devices such as NAS and servers, DVRs/surveillance systems, transportation and infrastructure, and emergency systems. It’s typically integrated in the back office, server room, and data center environment.

The UPS features color LCD panel for users to monitor power system and configure settings easily, and relay-type dry contact to perform local management. This model is designed with extended battery module auto-detection, which can automatically detect the quantity of connected Extended Battery Modules (EBM) to estimate UPS's runtime. The variable speed fans provide automatic thermal management based on power load to reduce noise and provide greater comfort for users.

Specifications

Power
Output frequency	50/60 Hz
Output power capacity	1 kVA
Output power	900 W
Input operation voltage (min)	160 V
Input operation voltage (max)	300 V
Output operation voltage (min)	208 V
Output operation voltage (max)	240 V
Surge energy rating	363 J
Maximum current	4.5 A
Power factor	0.9
Input power factor	0.99
Input current Total Harmonic Distortion (THD)	3%
Crest factor	3:1
Charging current	1.5 A
Efficiency (ECO mode)	95%
ECO mode	Yes
Input frequency	50/60 Hz
Ports & interfaces
Cable length	1.5 m
USB port	Yes
AC outlets quantity	8 AC outlet(s)
AC outlet types	C13 coupler
USB 2.0 ports quantity	1
Modem (RJ-11) ports	1
Ethernet LAN (RJ-45) ports	1
Performance
Audible alarm modes	Alarm when on battery, Fault, Low battery alarm, Overload alarm
UPS topology	Double-conversion (Online)
Response time	0 ms
EMI/RFI noise filtering	Yes
Surge protection	Yes
Surge protection features	Modem, Network, Telephone
Waveform	Pure sine
Power protection features	Surge protection
Audible alarm(s)	Yes
Features
Output frequency	50/60 Hz
Country of origin	China
Audible alarm modes	Alarm when on battery, Fault, Low battery alarm, Overload alarm
UPS topology	Double-conversion (Online)
Output power capacity	1 kVA
Response time	0 ms
Output power	900 W
Input operation voltage (min)	160 V
Input operation voltage (max)	300 V
Output operation voltage (min)	208 V
Output operation voltage (max)	240 V
Surge energy rating	363 J
Maximum current	4.5 A
EMI/RFI noise filtering	Yes
Surge protection	Yes
Surge protection features	Modem, Network, Telephone
Waveform	Pure sine
Power protection features	Surge protection
Power factor	0.9
Input power factor	0.99
Input current Total Harmonic Distortion (THD)	3%
Crest factor	3:1
Audible alarm(s)	Yes
Efficiency (ECO mode)	95%
ECO mode	Yes
Input frequency	50/60 Hz
Charging current	1.5 A
Battery
Battery technology	Sealed Lead Acid (VRLA)
Number of batteries supported	2
Typical backup time at half load	13.9 min
Typical backup time at full load	4.6 min
Hot-swap battery	Yes
Battery voltage	12 V
Battery capacity	9 Ah
Charging current	1.5 A
Replacement battery cartridge	RBP0156
Design
Country of origin	China
Rack capacity	2U
Form factor	Rackmount/Tower
Product colour	Black
Certification	CE, EAC, RoHS
Cable length	1.5 m
Housing material	Metal
Display type	LCD
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	20 - 90%
Storage relative humidity (H-H)	10 - 90%
Operating altitude	0 - 1500 m
Non-operating altitude	0 - 1500 m
Technical details
Output frequency	50/60 Hz
Harmonized System (HS) code	8504408590
Certificates
Certification	CE, EAC, RoHS
Packaging content
Cables included	USB cable
Weight & dimensions
Width	438 mm
Depth	430 mm
Height	88 mm
Weight	10.4 kg
Package width	540 mm
Package depth	550 mm
Package height	230 mm
Package weight	16.2 kg
Packaging data
Cables included	USB cable
Package width	540 mm
Package depth	550 mm
Package height	230 mm
Package weight	16.2 kg
Logistics data
Country of origin	China
Harmonized System (HS) code	8504408590
