Ubiquiti Networks Building-to-Building Bridge Network bridge White

60 Ghz, 17.2 dBi, EIRP 32 - 36.5 dBm, 10/100/1000 Ethernet Port, Bluetooth, 11 W, PoE

Description

60 GHz PtP link using 802.11ad with 5 GHz radio for backup. Ideal for high-throughput connectivity with a range of up to 500 m. 1.7+ Gbps bi-directional Plug and Play 60 GHz Bridge with 5 GHz Radio Redundancy, UniFi Controller Management, and range of up to 500 m UniFi® Building-to-Building Bridge is the ideal solution for short-range, high-throughput connectivity. Integration with the UniFi Controller makes bridging two networks seamless. As a pack of two radios, UniFi Building-to-Building Bridge contains everything you need to get up and running within minutes. Enjoy simple, easy-to-use gigabit connectivity anywhere.

Specifications

Antenna
Antenna gain level (max)	17.2 dBi
Wireless LAN features
Signal strength	36.5 dBm
Frequency band	5.15 - 5.875, 57-66 GHz
Antenna gain level (max)	17.2 dBi
Network
Networking standards	IEEE 802.3af
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Frequency band	5.15 - 5.875, 57-66 GHz
Ports & interfaces
Ethernet LAN	Yes
Features
Product type	Network bridge
Material	Polycarbonate
Product colour	White
Power
Power consumption (max)	11 W
Power source type	PoE
Power over Ethernet (PoE)	Yes
Operational conditions
Operating temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	5 - 95%
Certificates
Certification	CE, FCC, IC
Technical details
Material	Polycarbonate
Product colour	White
Quantity per pack	2 pc(s)
Harmonized System (HS) code	85176990
Weight & dimensions
Weight	376 g
Width	140 mm
Depth	140 mm
Height	90 mm
Packaging data
Quantity per pack	2 pc(s)
Logistics data
Harmonized System (HS) code	85176990
