PowerShield Centurion RT LiFePO4 1000VA uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 900 W 8 AC outlet(s)

1000 VA, 900 W, 8 Outlets, LiFePO4 Batteries, 380 × 438 × 88 mm, 10200 g

Key Features

• True double-conversion
• HID Communication via USB
• Output power factor 0.9
• User-friendly and electronic easy-shift LCD display
• Rack or Tower design
• Advanced ECO mode for energy saving
• Generator compatible
• Programmable power management outlets
• Emergency Power Off function (EPO)
• Hot swappable battery design
• Ideal for medium density power protection

Description

The Centurion LiFePO4 features true online double conversion and a Lithium-iron Phosphate advantage that includes extended battery life, lighter weight, faster recharge, higher performance and higher power density. As our highest single phase power density UPS, this sophisticated range will provide the most comprehensive protection for mission-critical devices such as sensitive networks, computers, servers, telecom applications, as well as industrial applications.

Specifications

Power
Output power capacity	1 kVA
Output power	900 W
Output operation voltage (min)	200 V
Output operation voltage (max)	240 V
Surge energy rating	1872 J
Efficiency	87%
Emergency Power Off (EPO)	Yes
Power factor	0.8
Input power factor	0.99
Crest factor	3:1
ECO mode	Yes
Input frequency	40 - 70 Hz
Performance
UPS topology	Double-conversion (Online)
Number of output phases	1
Number of input phases	1
Response time	4 ms
Waveform	Pure sine
Power protection features	Overcharge, Overdischarge, Overload, Short circuit
Noise level	50 dB
Features
UPS topology	Double-conversion (Online)
Output power capacity	1 kVA
Number of output phases	1
Number of input phases	1
Response time	4 ms
Output power	900 W
Output operation voltage (min)	200 V
Output operation voltage (max)	240 V
Surge energy rating	1872 J
Efficiency	87%
Emergency Power Off (EPO)	Yes
Waveform	Pure sine
Power protection features	Overcharge, Overdischarge, Overload, Short circuit
Power factor	0.8
Input power factor	0.99
Crest factor	3:1
Noise level	50 dB
ECO mode	Yes
Input frequency	40 - 70 Hz
Power source type	AC
Detachable power cord	Yes
Ports & interfaces
Emergency Power Off (EPO) connector	Yes
USB port	Yes
AC outlets quantity	8 AC outlet(s)
AC outlet types	C13 coupler
RS-232 ports	1
USB port type	USB Type-B
Battery
Battery technology	Lithium Iron Phosphate (LiFePO4)
Number of batteries supported	1
Battery recharge time	2 h
Battery voltage	12 V
Battery capacity	9 Ah
Design
Form factor	Rackmount/Tower
Product colour	Black
Certification	EN62040-1-1 2003, IEC60950-1-1 / EN62040-2 2006 / Directive 2011/65/EU
Cooling type	Active
Built-in fan	Yes
Control type	Buttons
Display type	LCD
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 90%
Technical details
Compliance certificates	RoHS
Cooling
Cooling type	Active
Built-in fan	Yes
Weight & dimensions
Width	438 mm
Depth	380 mm
Height	88 mm
Weight	10.2 kg
Certificates
Certification	EN62040-1-1 2003, IEC60950-1-1 / EN62040-2 2006 / Directive 2011/65/EU
