Ubiquiti UniFi USW-PRO-24 network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Silver

(24) Gigabit RJ45 ports, (2) 10G SFP+ ports, L2/L3, 1.3" touchscreen display

Key Features

• Layer 2 and Layer 3 features
• UniFi SmartPower RPS DC input
• Near-silent cooling
• Managed by UniFi Network Controller

Description

24-port switch with (24) Gigabit RJ45 ports and (2) 10G SFP+ ports. Powerful second-generation UniFi switching

UniFi Switch Pro 24 is a fully managed Layer 3 switch with (24) Gigabit Ethernet ports. (2) 10G SFP+ uplinks offer link aggregation for higher capacity and increased availability. The UniFi Switch Pro 24 features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing, static routing, and DHCP server. The UniFi Switch Pro 24 is an ideal aggregation and access layer switch for any UniFi solution – it combines innovative near-silent cooling with UniFi SmartPower RPS power redundancy. UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere.

Specifications

Management features
Switch layer	L2/L3
Switch type	Managed
Ports & interfaces
SFP+ module slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Network
10G support	Yes
Design
Rack mounting	Yes
Product colour	Silver
LED indicators	Yes
Performance
Harmonized System (HS) code	85176990
Technical details
Harmonized System (HS) code	85176990
Power
Power supply included	Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE)	No
Weight & dimensions
Width	442.4 mm
Depth	285.4 mm
Height	43.7 mm
Weight	3.5 kg
Logistics data
Harmonized System (HS) code	85176990
