NETGEAR GS308PP-100AJS network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

8-Port Gigabit Ethernet Unmanaged PoE+ Switch with FlexPoE

Key Features

• ETHERNET PORT CONFIGURATION: 8 Gigabit ports
• POWER-OVER-ETHERNET: 8 PoE+ ports with 83W total power budget, and includes NETGEAR FlexPoE making it expandable to 123W (w/separately purchased power supply module)
• PLUG-AND-PLAY: Simple set up with no software to install or configuration needed
• PoE POWER AUTO-BALANCE AND ALLOCATION – NETGEAR’s unique PoE technology automatically balances the PoE power at the most granular level on each port, depending on the device needs
• VERSATILE MOUNTING OPTIONS: Supports desktop, wall or rackmount placement, and includes all the necessary mounting hardware in the box
• SILENT OPERATION: The fanless design means zero added noise wherever its located, making it ideal for noise-sensitive environments
• ENERGY EFFICIENT: Designed to optimize power usage lowering its cost to operate. Most models are compliant with IEEE802.3az Energy Efficient Ethernet mode
• BUILT TO LAST: Every NETGEAR Network switch is rigorously tested for reliability, quality, and performance

Description

NETGEAR 300 Series Gigabit Ethernet Unmanaged Switches with PoE provide easy, reliable, and affordable network connectivity for home and small offices. With these unmanaged plug-and-play switches, you can expand your network connections to multiple devices instantly.

The unmanaged switches provides power and data from a single Ethernet (CAT-5e) cable to devices such as IP cameras, VoIP/ Internet-based phones, wireless access points, etc. The majority of these models also support PoE power auto-balance and allocation feature.

NETGEAR’s unique PoE technology automatically balances the PoE power based on the device needs independent of PoE class detected. These switches deliver the power the device needs, at the most granular level

Specifications

Management features
Switch type	Unmanaged
Quality of Service (QoS) support	Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power connector	DC-in jack
Network
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Full duplex	Yes
Flow control support	Yes
Auto-sensing	Yes
Auto MDI/MDI-X	Yes
10G support	No
Auto-negotiation	Yes
Data transmission
Packet forwarding rate (1 Gbps)	1448000 pps
Jumbo frames	9216
MAC address table	4000 entries
Switching capacity	16 Gbit/s
Latency (1 Gbps)	3 µs
Jumbo frames support	Yes
Packet buffer memory	0.192 MB
Design
Wall mountable	Yes
Rack mounting	Yes
Product colour	Black
LED indicators	Activity, Link, PoE, Power, Speed
Housing material	Metal
Certification	CE Mark, FCC Part 15 Class A, IC Class A, RCM, VCCI, BSMI, KC
Performance
Mean time between failures (MTBF)	2752476 h
Packet buffer memory	0.192 MB
Auto-negotiation	Yes
Harmonized System (HS) code	85176990
Power
Power consumption (max)	87.9 W
Input current	1.66 A
DC input voltage	54 V
Power connector	DC-in jack
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port	30 W
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	8
Total Power over Ethernet (PoE) budget	130 W
Power over Ethernet (PoE) type supported	PoE+
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	0 - 90%
Operating altitude	0 - 3000 m
Heat dissipation	300.6 BTU/h
Weight & dimensions
Width	236 mm
Depth	102 mm
Height	27 mm
Weight	600 g
Technical details
Harmonized System (HS) code	85176990
Certificates
Certification	CE Mark, FCC Part 15 Class A, IC Class A, RCM, VCCI, BSMI, KC
Logistics data
Harmonized System (HS) code	85176990
