TP-Link TL-SF1008LP network switch Unmanaged Fast Ethernet (10/100) Power over Ethernet (PoE) Black

8-Port 10/100Mbps Desktop Switch with 4-Port PoE

Description

Professional Fast Ethernet Switch with 4 PoE Ports
Plug and Play, with PoE Transmission for Surveillance up to 250 m

Dedicated 4-Port PoE Switch (41 W Budget) for Numerous Applications
Compliance with the 802.3af PoE standard supports up to 15.4 W on each PoE port. The total 41 W PoE power budget* for the 4× PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.

Priority Video
Quality Guaranteed
Quality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 1–2 when one-touch Priority Mode is on.

Intelligent Power Management
When total power consumption exceeds 41 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.

Durable Metal Casing
The interior components of TL-SF1008LP are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SF1008LP delivers switching performance you can depend on.

Specifications

Management features
Switch type	Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Fast Ethernet (copper) ports quantity	8
Power connector	DC-in jack
Copper ethernet cabling technology	10GBASE-T, 100BASE-TX
Network
MAC address auto-learning supported	Yes
MAC address auto-aging supported	Yes
Networking standards	IEEE 802.3af, IEEE 802.3x
Full duplex	Yes
Copper ethernet cabling technology	10GBASE-T, 100BASE-TX
Flow control support	Yes
Auto MDI/MDI-X	Yes
10G support	No
Auto-negotiation	Yes
Half duplex	Yes
Data transmission
Jumbo frames	2000
MAC address table	2000 entries
Switching capacity	1.6 Gbit/s
Store-and-forward	Yes
Jumbo frames support	Yes
Forwarding rate	1.1904 Mpps
Security
DHCP features	DHCPv6 relay
Protocols
Routing protocols	OSPF
IPv4 & IPv6 features	IPv6 portal
Design
Wall mountable	Yes
Rack mounting	No
Stackable	No
Product colour	Black
LED indicators	Yes
Housing material	Metal
Number of fans	0 fan(s)
Performance
Fanless	Yes
Stackable	No
Auto-negotiation	Yes
Harmonized System (HS) code	85176990
Power
Power consumption (max)	47.1 W
Power supply included	No
AC input voltage	220 V
AC input frequency	50 Hz
Input current	0.81 A
DC input voltage	53.5 V
Power source	DC/PoE
Power connector	DC-in jack
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	4
Total Power over Ethernet (PoE) budget	41 W
Other features
Bandwidth	1.6 Gbit/s
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Heat dissipation	160.61 BTU/h
Weight & dimensions
Width	171 mm
Depth	98 mm
Height	27 mm
Packaging content
User guide	Yes
Cables included	AC
AC adapter included	Yes
Packaging data
AC adapter included	Yes
Package width	223 mm
Package depth	280 mm
Package height	68 mm
Package weight	750 g
User guide	Yes
Cables included	AC
Sustainability
Sustainability compliance	Yes
IPv4 & IPv6 features
IPv4 & IPv6 features	IPv6 portal
Technical details
Harmonized System (HS) code	85176990
Sustainability compliance	Yes
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS
Certificates
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS
Logistics data
Harmonized System (HS) code	85176990
