PowerShield Defender 1200VA uninterruptible power supply (UPS) Line-Interactive 1.2 kVA 720 W 6 AC outlet(s)

1200 VA, 720 W, 6 Outlets, 2 Batteries, 12 V, 7 Ah, 397 × 146 × 205 mm, 11100 g

Key Features

• Stylish and informative LCD display
• Surge Protection, Best in its Class
• Excellent microprocessor control guarantees high reliability
• Australian outlets for UPS and Surge Protection
• Boost and buck AVR for voltage stabilization
• User replaceable batteries
• Silent Operation (No fans included)
• Auto restart while AC is recovering
• Off-mode charging
• Cold start function
• USB communication with sophisticated NetGuard software

Description

The Defender Range uses Automatic Voltage Regulation (AVR) to minimise the effects of fluctuations in input voltage, protecting your valuable equipment from power line disturbances.
To protect your valued equipment against damaging surges, the Defender has been designed to incorporate the best surge protection in its class.

Specifications

Power
Output power capacity	1.2 kVA
Output power	720 W
Input operation voltage (min)	177 V
Input operation voltage (max)	290 V
Output operation voltage (max)	240 V
Surge energy rating	936 J
Output voltage regulation	10%
Input frequency	50/60 Hz
Performance
UPS topology	Line-Interactive
Number of output phases	1
Number of input phases	1
Response time	6 ms
Surge protection	Yes
Waveform	Sine
Power protection features	Battery discharge, Overcharge, Overload, Short circuit
Noise level	5 dB
Features
UPS topology	Line-Interactive
Output power capacity	1.2 kVA
Number of output phases	1
Number of input phases	1
Response time	6 ms
Output power	720 W
Input operation voltage (min)	177 V
Input operation voltage (max)	290 V
Output operation voltage (max)	240 V
Surge energy rating	936 J
Surge protection	Yes
Waveform	Sine
Power protection features	Battery discharge, Overcharge, Overload, Short circuit
Output voltage regulation	10%
Noise level	5 dB
Input frequency	50/60 Hz
Power source type	AC
Detachable power cord	No
Ports & interfaces
USB port	Yes
AC outlets quantity	6 AC outlet(s)
USB port type	USB Type-B
Battery
Number of batteries supported	2
Battery recharge time	6 h
Battery voltage	12 V
Battery capacity	7 Ah
Design
Form factor	Tower
Product colour	Black
Certification	(A-tick PSD650) EN62040-1 -1 2003, IEC60950-1 : 2001, EN62040-2 2006, Directive 2011/65/EU
Control type	Buttons
Display type	LCD
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90%
Technical details
Compliance certificates	RoHS
Weight & dimensions
Width	146 mm
Depth	397 mm
Height	205 mm
Weight	11.1 kg
Certificates
Certification	(A-tick PSD650) EN62040-1 -1 2003, IEC60950-1 : 2001, EN62040-2 2006, Directive 2011/65/EU
