Simplecom SD326 storage drive docking station USB 3.2 Gen 1 (3.1 Gen 1) Type-B Black

USB3.0, SATA 3, 2.5", 3.5", 480Mbps

Key Features

• Designed for direct insertion of one 2.5 inch or 3.5 inch SATA HDD/SSD
• USB 3.0 SuperSpeed Interface, transfer rates up to 5Gbps
• Backwards-Compatible with USB 2.0, transfer rates up to 480Mbps
• Touch Control ON/OFF switch
• LED light indicates Power and Activity status
• Hot-swappable, plug and play, no drivers needed
• Support UASP (USB Attached SCSI) for Windows 8 and above, Mac OS 10.8 and above
• Compatible Operating Systems: Windows XP and above (32/64-bit), Mac OS 10.4 and above, Linux

Description

Simplecom SD326 USB 3.0 to SATA Hard Drive Docking Station offers swappable access to 2.5" and 3.5" SATA HDD/SSD without having to mount the hard drive or install it in an enclosure. It provides a simple, fast, and cost effective solution for data recovery, drive imaging, or any environment that requires fast access to 3.5" or 2.5" drives. The super speed USB 3.0 interface supports transfer rate up to 5Gbps.

Specifications

Hard drive
Storage media type	HDD, SSD
Storage drive interface	Serial ATA, Serial ATA II, Serial ATA III
Storage drive sizes supported	2.5,3.5,5.25"
Number of storage drives supported	1
Ports & interfaces
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-B
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	1
DC-in jack	Yes
Technical details
Maximum data transfer rate	5 Gbit/s
Product colour	Black
Plug and Play	Yes
Hot-swap	Yes
Features
Maximum data transfer rate	5 Gbit/s
LED indicators	Activity, Power
Product colour	Black
Plug and Play	Yes
Hot-swap	Yes
Cooling
Built-in fan	No
Power
AC input voltage	100 - 240 V
Output voltage	12 V
Output current	2 A
Indication
LED indicators	Activity, Power
Software
Mac compatibility	Yes
Windows operating systems supported	Windows 10,Windows 11,Windows 8,Windows 8.1
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Ethernet LAN features
LED indicators	Activity, Power
Packaging content
AC adapter included	Yes
Cables included	USB
Manual	Yes
