Ubiquiti UniFi Dream Machine Pro Managed Gigabit Ethernet (10/100/1000) White

8 x Gigabit LAN, 1 x Gigabit WAN, 442.4 x 43.7 x 285.6 mm, 3.90 kg

Key Features

• All-in-one 1U rack appliance for small to medium sized businesses
• Combines new UniFi OS with 8-port switch and security gateway
• UniFi Protect video surveillance NVR with off-the-shelf 3.5" HDD support
• 8-port Gigabit Switch with 1 Gbps RJ45 and 10G SFP+ LAN
• Enterprise-class IPS/IDS, DPI, and Wi-Fi AI capabilities
• Powered by fast 1.7 GHz quad-core processor

Description

All-in-one enterprise security gateway & network appliance for small to medium-sized businesses. The optimal experience for larger networks

UniFi Dream Machine Pro (UDM-Pro) is an all-in-one enterprise network appliance. UDM-Pro integrates all current and upcoming UniFi controllers with a security gateway, 10G SFP+ WAN, 8-port Gbps switch and off-the-shelf 3.5" HDD support.

Specifications

Management features
Switch type	Managed
Ports & interfaces
SFP+ module slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	9
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
Network
10G support	Yes
Data transmission
Throughput	3.5 Gbit/s
Design
Rack mounting	Yes
Product colour	White
LED indicators	Yes
Certification	CE, FCC, IC
Performance
Processor frequency	1700 MHz
Internal memory	4096 MB
Flash memory	16000 MB
Built-in processor	Yes
Processor model	ARM Cortex-A57
Harmonized System (HS) code	85176990
Power
Power consumption (max)	33 W
Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Redundant power supply (RPS) support	Yes
Number of power supply units	1
DC input voltage	12 V
Weight & dimensions
Width	442.4 mm
Depth	285.6 mm
Height	43.7 mm
Weight	3.9 kg
Technical details
Harmonized System (HS) code	85176990
Certificates
Certification	CE, FCC, IC
Logistics data
Harmonized System (HS) code	85176990
