Ubiquiti UniFi USW-ENTERPRISE-48-POE network switch Managed L3 2.5G Ethernet (100/1000/2500) White

USW Enterprise 48 PoE, L3, 2.5GbE, 802.3at PoE+ RJ45 ports, (4) 10G SFP+ ports, 720W

Key Features

• (1) 1.3" LCM color touchscreen with AR switch management
• (48) 2.5GbE, 802.3at PoE+ RJ45 ports
• (4) 10G SFP+ ports
• (1) USP RPS DC input
• 720W total PoE supply
• Layer 3 switching features

Description

The Switch Enterprise 48 PoE (USW Enterprise 48 PoE) is a fully managed switch with (48) 2.5GbE, 802.3at PoE+ RJ45 ports, (4) 10G SFP+ ports, and a 720W total PoE supply. Along with its Layer 3 functionality, this switch offers an extensive suite of Layer 2 switching protocols, including port-specific operation modes (switching, mirroring, or aggregate).The USW Enterprise 48 PoE also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights.

Additionally, the USW Enterprise 48 PoE offers enhanced power supply failure protection when connected to the SmartPower Redundant Power System (USP RPS sold separately). This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Specifications

Management features
Reset button	Yes
Switch layer	L3
Switch type	Managed
Web-based management	Yes
Ports & interfaces
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	2.5G Ethernet (100/1000/2500)
Network
Networking standards	IEEE 802.3af, IEEE 802.3at
10G support	Yes
Data transmission
Switching capacity	360 Gbit/s
Forwarding rate	238.095 Mpps
Throughput	160 Gbit/s
Design
Reset button	Yes
Product colour	White
Housing material	Steel
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Redundant power supply (RPS) support	Yes
Input current	10 A
DC input voltage	52 V
Power source	AC/DC
Power over Ethernet (PoE)
Power over Ethernet (PoE)	No
Operational conditions
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	442 mm
Depth	400 mm
Height	44 mm
Weight	6.2 kg
Performance
Harmonized System (HS) code	85176990
Technical details
Harmonized System (HS) code	85176990
Compliance certificates	CE
Certificates
Compliance certificates	CE
Logistics data
Harmonized System (HS) code	85176990
