Brother ADS-4900W scanner ADF + Sheet-fed scanner 600 x 600 DPI A4 Black, White

ADS-4900W Professional desktop document scanner, ADF, 60 ppm, 120 ipm, 600 x 600/1200 x 1200 dpi, LAN, WiFi, 62dB, USB

Key Features

• Scan up to 60 pages per minute
• 2-sided scan up to 60 pages per minute
• 100 sheet Automatic Document Feeder (ADF)
• 5GHz Wi-Fi and wired connectivity
• SuperSpeed USB3.0
• Scan directly to USB host
• Large intuitive 10.9cm touchscreen with 56 configurable shortcuts
• Personalised multi-user experience
• Secure workgroup sharing
• Advanced image processing and batch scanning
• Features Auto Start Scan, Ultrasonic Multifeed Sensor, Separation Switch, Scan Preview, CIS Cleaning Alarm
• Includes Brother ScanEssentials software
• Driver compatibility with TWAIN (WIN and macOS), WIA, ISIS, Linux SANE

Description

With high-performance wired and wireless connectivity and dedicated user touchscreen. Ideal for high-volume, secure batch scanning for collaborative and complex workflows.

For uninterrupted high-volume, batch scanning. With the simplicity of one-touch scanning, securely capture, send and receive business documents with ease, whether they're at home or in the office.

Fast and reliable

With an in-built ultrasonic multifeed to eliminate misfeeds, the ADS-4900W has the largest sheet ADF capacity (100 sheets) and is the fastest in the range, scanning up to 60 pages per minute, or one every second. The separation switch enables very thick and thin documents, plastic cards and crumpled paper to smoothly feed through with ease.

Simple and intuitive

Set up a dedicated user interface with one-touch scanning and the ability to add up to 56 shortcuts to frequently used destinations. You can also use an optional external cardreader to make the scanning process even easier. Just tap the card and add your documents into the ADF to automatically and securely capture the information on the page.

Advanced connectivity

With 5GHz wireless connectivity, network, USB3.0 and USB host, you can securely scan documents and share with colleagues.

Advanced image capture and processing

Effortless and impressive image capture and processing - from easily referencing and locating scanned pages with the digital imprinter, to optimising image quality through the automatic vertical streaks and moiré reduction tools.

The document separation functionality also automatically detects and removes any scanned blank pages, thus reducing file sizes and document preparation time.

Brother ScanEssentials

Our ScanEssentials software provides you with additional features which you can tailor to your business. For added security, you can set up passwords and protect your workflows, with the option to save your documents in a variety of formats.

The metadata function can also read barcodes or specific strings of text to easily facilitate the separation and file naming of documents.

Industry recognised software

Increase post-scanning productivity with industry recognised software including Kofax and Newsoft, available as standard with device.

Specifications

Scanning
Output greyscale depth	8 bit
Maximum scan size	215.9 x 355.6 mm
Optical scanning resolution	600 x 600 DPI
Enhanced scan resolution	1200 x 1200 DPI
Colour scanning	Yes
Duplex scanning	Yes
Input colour depth	48 bit
Output colour depth	24 bit
Greyscale levels	256
ADF scan speed (b/w, A4)	60 ppm
ADF scan speed (colour, A4)	60 ppm
Duplex ADF scan speed (b/w, A4)	120 ipm
Duplex ADF scan speed (colour, A4)	120 ipm
Design
Built-in display	Yes
Product colour	Black, White
Display	LCD
Display diagonal	10.9 cm (4.3")
Touchscreen	Yes
Scanner type	ADF + Sheet-fed scanner
Colour display	Yes
Control type	Touch
Performance
Sensor type	Dual CIS
Light source	LED
Scan file formats	JPEG, PDF, TIFF
Daily duty cycle (max)	9000 pages
Scan to	E-mail Server, FTP, HTTP, PC, SMB
Maximum duty cycle	180000 pages per month
Scan drivers	ISIS, SANE, TWAIN, WIA
Scanning noise level	62 dB
Ultrasonic sensor	Yes
Input capacity
Auto document feeder (ADF) input capacity	100 sheets
Paper handling
Maximum scan width	21.6 cm
Maximum scan length	5 m
Maximum ISO A-series paper size	A4
Scanning media types supported	Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper
Auto Document Feeder (ADF) media weight	25 - 413 g/m²
Media thickness (min)	0.08 mm
Long-paper mode	Yes
Card thickness (max)	1.32 mm
Paper tray media weight	25 - 413 g/m²
Ports & interfaces
USB port	Yes
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
Network
Supported network protocols (IPv6)	RA, DNS Resolver, mDNS, LLMNR responder, Web Services(Scan), SNTP Client, HTTP/HTTPS server, ICMPv6
Ethernet LAN	Yes
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	AES, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS, TKIP, TLS, WEP, WPA-PSK, WPA2-AES, WPA2-PSK, WPA3
Supported network protocols (IPv4)	DHCP, APIPA (Auto IP), WINS/NetBIOS, DNS Resolver, mDNS, SNMPv1/v2c/v3, ICMP, Web Services(Scan), HTTP/HTTPS server, LLMNR responder, SNTP Client, LDAP
IPv6 support	Yes
Power
Auto power off	Yes
Power supply type	AC
Power consumption (typical)	34 W
Power consumption (standby)	7.7 W
Power consumption (off)	0.1 W
Power consumption (sleep)	1.7 W
Output voltage	24 V
Output current	1.9 A
Sleep mode	Yes
Weight & dimensions
Width	288 mm
Depth	334 mm
Height	393 mm
Weight	3.81 kg
Package width	393 mm
Package depth	288 mm
Package height	334 mm
Package weight	4.6 kg
Packaging data
Package width	393 mm
Package depth	288 mm
Package height	334 mm
Package weight	4.6 kg
Quantity per pack	1 pc(s)
Packaging content
Cables included	AC, USB
Technical details
Maximum scan width	21.6 cm
Pallet gross height	18.1 cm
Supported network protocols (IPv6)	RA, DNS Resolver, mDNS, LLMNR responder, Web Services(Scan), SNTP Client, HTTP/HTTPS server, ICMPv6
Master (outer) cases per pallet layer	8 pc(s)
Harmonized System (HS) code	84716070
Pallet type	800 x 1200 mm
Features
Country of origin	China
System requirements
Windows operating systems supported	Yes
Server operating systems supported	Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Mac operating systems supported	Yes
Linux operating systems supported	Yes
Operational conditions
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	10 - 90%
Certificates
Certification	GS Mark, WHQL, WHQL, ISIS, Wi-Fi CERTIFIED - WPA3 Enterprise, WPA3 Personal, Wi-Fi Protected Setup, Wi-Fi Direct, KofaxTM 5,10 - VRS Elite 5.2.0, Kofax Express 3.3.0
Other features
Cable lock slot	Yes
Certification	GS Mark, WHQL, WHQL, ISIS, Wi-Fi CERTIFIED - WPA3 Enterprise, WPA3 Personal, Wi-Fi Protected Setup, Wi-Fi Direct, KofaxTM 5,10 - VRS Elite 5.2.0, Kofax Express 3.3.0
Spare part retention	5 year(s)
Pallet gross weight	186 kg
Ethernet LAN	Yes
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	AES, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS, TKIP, TLS, WEP, WPA-PSK, WPA2-AES, WPA2-PSK, WPA3
Scanner type	ADF + Sheet-fed scanner
Country of origin	China
Products per pallet	40 pc(s)
Layers per pallet	5 pc(s)
Master (outer) cases per pallet	40 pc(s)
Quantity per pack	1 pc(s)
Logistics data
Pallet gross weight	186 kg
Country of origin	China
Products per pallet	40 pc(s)
Layers per pallet	5 pc(s)
Master (outer) cases per pallet	40 pc(s)
Quantity per pack	1 pc(s)
Pallet gross height	18.1 cm
Master (outer) cases per pallet layer	8 pc(s)
Harmonized System (HS) code	84716070
