Ubiquiti U6-Mesh 4800 Mbit/s White Power over Ethernet (PoE)

WIFI 6, (1) GbE RJ45 port, IPX5, 802.3af PoE, 802.11a/b/g/n/ac/ax, WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3), 4.8 Gbps

Key Features

• High-efficiency 4x4 WiFi 6 (802.11ax)
• 5 GHz (4x4 MU-MIMO and OFDMA) band with a 4.8 Gbps throughput rate
• 2.4 GHz (2x2 MIMO) band with a 573.5 throughput rate
• Operates at full 4x4 MIMO with 160 MHz bandwidth
• Powered with 802.3af PoE (PoE adapter included)

Description

Indoor/outdoor, 4x4 WiFi 6 access point designed for mesh applications.
The Access Point WiFi 6 Mesh (U6 Mesh) is a high-performance, four-stream WiFi 6 access point that provides best-in-class signal meshing to enhance the wireless coverage of home and enterprise networks. The U6 Mesh can reach an aggregate throughput rate up to 5.3 Gbps with its 5 GHz (4x4 MU-MIMO and OFDMA) and 2.4 GHz (2x2 MIMO) bands. This access point also operates at full 4x4 MIMO with 160 MHz channels to create high-capacity wireless uplinks and facilitate faster data transfer. The sleek U6 Mesh is discreet enough to stage anywhere in your home or office, but also rugged enough to reliably operate outdoors thanks to its IPX5-rated, waterproof housing. The U6 Mesh is a plug-and-play device designed to easily extend your wireless signal to ensure full, seamless coverage and high-quality WiFi connectivity. It can be set up in minutes and fully managed with the UniFi Network web application or mobile app.

Specifications

Performance
2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	4800 Mbit/s
Ethernet LAN data rates	1000 Mbit/s
Frequency band	2.4 - 5 GHz
VLAN support	Yes
Reset button	Yes
Quality of Service (QoS) support	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3af
MIMO type	Multi User MIMO
MIMO	Yes
Features
2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	4800 Mbit/s
Ethernet LAN data rates	1000 Mbit/s
Frequency band	2.4 - 5 GHz
VLAN support	Yes
Quality of Service (QoS) support	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3af
Cabling technology	10/100/1000Base-T(X)
Bluetooth	Yes
MIMO type	Multi User MIMO
MIMO	Yes
Maximum data transfer rate (2.4 GHz)	573.5 Mbit/s
Maximum data transfer rate (5 GHz)	4800 Mbit/s
Security
Security algorithms	WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Cabling technology	10/100/1000Base-T(X)
Power
Power consumption (max)	11.4 W
Input current	0.32 A
Power over Ethernet (PoE)	Yes
AC input voltage	44 - 57 V
Design
Placement	Ceiling, Pole, Table, Wall
International Protection (IP) code	IPX5
Housing material	Aluminium, Plastic
Reset button	Yes
LED indicators	Yes
Product colour	White
Antenna
Antenna type	Internal
Antenna gain level (max)	5 dBi
Technical details
Harmonized System (HS) code	85176990
Weight & dimensions
Width	48.5 mm
Depth	48.5 mm
Height	159.5 mm
Weight	400 g
Packaging data
PoE adapter included	Yes
Packaging content
PoE adapter included	Yes
Quantity per pack	1 pc(s)
Operational conditions
Operating relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	-30 - 60 °C
Logistics data
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
